FMS 80mm Integral EDF PNP

The 80mm Integral, officially authorized by TomaHawk, stands out in the realm of sport EDF JETs with its unique design and outstanding performance. Infused with a futuristic artistic design, it transforms flying into a stylish journey. The 80mm Integral boasts a powerful propulsion system, allowing pilots to effortlessly experience various control techniques and revel in the thrill of high-speed flight. Coupled with its distinctive red and blue paint scheme harmonizing with contour curves, it radiates a tactile and highly recognizable quality, effortlessly capturing attention whether in the sky or on the runway.

Features

• Power system: High-quality 100A ESC, 3665-KV2000 in-runner motor, 80mm 12 bladed fan.
• Full-metal CNC landing gear, trailing-link suspension, highly precise and robust.
• Full use of 13g digital metal servos for improved precision and torque.
• Large tires- suitable for rough-field operations.
• Glueless assembly. The aircraft is built with screws.
• Environmentally friendly water-based paint.
• Buckle design latch prevents unexpected canopy release in flight.
• Improved plug-type connectors for added durability and reliability.
• Added navigation lights on the wings and taxi lights on the bottom of the fuselage for a fun flight.
• Striking and attractive paint scheme.

Needed to Complete

PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. The transmitter, receiver, battery, and charger are not included.

Specifications

Wingspan	1060mm /41.7in
Overall Length	1190mm /46.8in
Flying Weight	Around 2500g
Motor Size	3665-KV2000
ESCA	100A
Servo	13gX8pcs
Radio	6CH Channel
CG (center of gravity)	155-165mm
EDF	80mm Ducted Fan 12-blade
Recommended Battery	22.2V 4000mAh-5000mAh 45c
Battery Compartment Size	160*55*45mm
Aileron	Yes
Rudder	Yes
Flaps	Yes
Retracts	Yes
Approx. Flying Duration	3 minutes
Minimum Age Recommendation	14+
Assembly Time	10 minutes
Wing Load	116 g/dm² ( 0.23oz/in²)
Wing Area	21.5dm² ( 333sq.in)
